Fielder® FCProduct Code (REF): AGP140001
Fielder FC uses a polymer-jacketed shaft for smooth, low-friction tracking through tortuous coronary segments, serving as a general frontline wire for routine PCI where atraumatic navigation is prioritized over penetrating force.
Available under product codes AGP140001, AGP140001J, AGP140301, AGP140301J.
Sizes & Specifications
- Diameter
- 0.014 in (0.36 mm)
- Usable length
- 180 cm / 300 cm
- Tip load
- ≈ 0.8 gf
- Coating
- Polymer + full-length hydrophilic
Manufacturer: Asahi Intecc Co., Ltd. · Reference source: medical.asahi-intecc.com
Design & Technology
Technical characteristics and diagrams as published by Asahi Intecc.
Structure
Product Identification & Specifications
Reference identifiers for procurement, registration and tender documentation.
| Product Code | AGP140001 |
|---|---|
| REF Numbers | AGP140001, AGP140001J, AGP140301, AGP140301J |
| Manufacturer | Asahi Intecc Co., Ltd. |
| Brand | Asahi Intecc |
| Product Family | Coronary Guidewires |
| Country Availability | Tajikistan, Afghanistan |
Clinical Applications
The Fielder® FC is a frontline guidewire in the Coronary Guidewires family from Asahi Intecc Co., Ltd., used by interventional specialists in procedures where a frontline guidewire of this class is indicated. It is supplied in 4 configurations (catalog codes AGP140001 through AGP140301J) to match anatomical and procedural requirements.
For the complete indications for use, contraindications and instructions for use (IFU), request the official Asahi Intecc documentation through our clinical team. Modern Medical Solutions supplies the Fielder® FC to hospitals and cath labs across Tajikistan and Afghanistan.
Ordering Information
Catalog reference codes as published by Asahi Intecc. Contact us to confirm current availability.
| Product Name | Catalog No. | Tip Shape | Usable Length | Outer Diameter | Coil Length | Radiopaque Length | Coating | Coating Length |
|---|---|---|---|---|---|---|---|---|
| Fielder FC | AGP140001 | Straight | 180cm | 0.36mm (0.014") | 11cm | 3cm | Polymer＋Hydrophilic | 20cm |
| Fielder FC | AGP140001J | J | 180cm | 0.36mm (0.014") | 11cm | 3cm | Polymer＋Hydrophilic | 20cm |
| Fielder FC | AGP140301 | Straight | 300cm | 0.36mm (0.014") | 11cm | 3cm | Polymer＋Hydrophilic | 20cm |
| Fielder FC | AGP140301J | J | 300cm | 0.36mm (0.014") | 11cm | 3cm | Polymer＋Hydrophilic | 20cm |
Downloads & Documentation
Instructions for use (IFU), technical datasheets and clinical literature for the Fielder® FC are available on request from our clinical team.
Request DocumentationFrequently Asked Questions
- What is the Fielder® FC used for?
- The Fielder® FC is a frontline guidewire manufactured by Asahi Intecc, used by interventional physicians for precision vascular access procedures. Contact our clinical team for the full indications for use and instructions for use (IFU).
- What sizes does the Fielder® FC come in?
- The Fielder® FC is available in the following configurations: Diameter 0.014 in (0.36 mm), Usable length 180 cm / 300 cm, Tip load ≈ 0.8 gf, Coating Polymer + full-length hydrophilic.
- How can I order the Fielder® FC?
- Modern Medical Solutions is the authorized Asahi Intecc distributor for Tajikistan and Afghanistan. Submit a documentation or ordering request through our contact form and our clinical team will confirm availability and lead time.
